| Ürün Kodu | d1 (mm) | P adım | L1 (mm) | L2 (mm) | d2 (mm) | k (h12) (mm) |
| B00100040200 | M2 | 0.4 | 40 | 8 | 2,8 | 2,1 |
| B00100040250 | M2,5 | 0.45 | 40 | 9 | 2,8 | 2,1 |
| B00100040300 | M3 | 0.5 | 40 | 11 | 3,5 | 2,7 |
| B00100040350 | M3,5 | 0.6 | 45 | 13 | 4,0 | 3,0 |
| B00100040400 | M4 | 0.7 | 45 | 13 | 4,5 | 3,4 |
| B00100040450 | M4.5 | 0.75 | 50 | 16 | 6,0 | 4,9 |
| B00100040500 | M5 | 0.8 | 50 | 16 | 6,0 | 4,9 |
| B00100040600 | M6 | 1 | 56 | 19 | 6,0 | 4,9 |
| B00100040700 | M7 | 1 | 56 | 19 | 6,0 | 4,9 |
| B00100040800 | M8 | 1.25 | 63 | 22 | 6,0 | 4,9 |
| B00100040900 | M9 | 1.25 | 63 | 22 | 7,0 | 5,5 |
| B00100041000 | M10 | 1.5 | 70 | 24 | 7,0 | 5,5 |
| B00100041100 | M11 | 1.5 | 70 | 24 | 8,0 | 6,2 |
| B00100041200 | M12 | 1.75 | 75 | 28 | 9,0 | 7,0 |
| B00100041400 | M14 | 2 | 80 | 30 | 11,0 | 9,0 |
| B00100041600 | M16 | 2 | 80 | 32 | 12,0 | 9,0 |
| B00100041800 | M18 | 2.5 | 95 | 34 | 14,0 | 11,0 |
| B00100042000 | M20 | 2.5 | 95 | 34 | 16,0 | 12,0 |
| B00100042200 | M22 | 2.5 | 100 | 34 | 18,0 | 14,5 |
| B00100042400 | M24 | 3 | 110 | 38 | 18,0 | 14,5 |
| B00100042600 | M26 | 3 | 110 | 38 | 20 | 16 |
| B00100042700 | M27 | 3 | 110 | 38 | 20 | 16,0 |
| B00100042800 | M28 | 3 | 110 | 38 | 20 | 16 |
| B00100043000 | M30 | 3.5 | 125 | 45 | 22,0 | 18,0 |
| B00100043300 | M33 | 3.5 | 125 | 50 | 25,0 | 20,0 |
| B00100043600 | M36 | 4 | 150 | 56 | 28,0 | 22 |
| B00100043900 | M39 | 4 | 150 | 60 | 32 | 24 |
| B00100044200 | M42 | 4.5 | 150 | 60 | 32 | 24 |
| B00100044500 | M45 | 4.5 | 160 | 65 | 36 | 29 |
| B00100044800 | M48 | 5 | 180 | 70 | 36 | 29 |
| B00100045200 | M52 | 5 | 180 | 70 | 40 | 32 |
| B00100045600 | M56 | 5.5 | 200 | 70 | 40 | 35 |
